Applicable card: Contactless RFID MIFARE ONE card. Mechanical Key
Power supply: 4pcs standard AA alkaline batteries.
Battery life: About 10 months in normal state, depending on usage and climatic conditions.
Low voltage warning: When power’s voltage is less 4.5V, there will be warning when
unlock. The lock still can be unlocked about 100 times before the batteries are replaced.
Static consumption: 12uA
Dynamic consumption: 200mA
Open time: The lock will be locked again automatically 7 seconds after unlocking.
Emergency unlocking: The door can be unlocked by Master Card or Mechanical key.
Installation request: To be installed on the door, with the door thickness between 33mm to 60mm.
Panel size: 225mm( Height) ×70mm (Width)
Mortise size: Standard single latch 60mm or 70mm
Weatherproofing: Waterproof technology with waterproof coating on PCB, all around waterproof gasket to prevent water, dust and sand from seeping in.
Emergency USB battery port
Handle orientation: left hand push to open, right hand push to open; left hand pull to open, right hand pull to open.
All locks are custom made to order and are non refundable.
